AM811F 电池模块

AM811F是一款电池模块，主要用于AC 800F系统。

以下是关于AM811F的一些主要参数和特性：

功能：提供备用电池，用于在AC 800F上启用冗余电池能量备份。

环境条件：

允许的环境温度范围是0°C到60°C。

允许的模块内部温度范围是0°C到70°C。

温度梯度在运行中为1°C/分钟，符合DIN IEC 68 第14部分/EN 60068-2-14标准。

运输和储存温度范围为-25°C到+85°C。

相对湿度要求是非冷凝，年平均值≤80%，每年最多30天可以≤95%湿度。

电气保护：

安全等级为II。

所有连接器的过电压类别为II，污染等级为2。

其他特性：符合电磁兼容性(EMC)的相关指令和标准。

抗噪性符合相关标准。

符合工业标准，如NAMUR 21/8.98。

The AM811F is a battery module mainly used in AC 800F systems.

Here are some of the main parameters and features of the AM811F:

Function: Provides a backup battery for enabling redundant battery energy backup on the AC 800F.

Environmental Conditions:

The allowable ambient temperature range is 0°C to 60°C.

The allowed temperature range inside the module is 0°C to 70°C.

The temperature gradient is 1°C/ min in operation, according to DIN IEC 68 Part 14 /EN 60068-2-14.

Transport and storage temperatures range from -25°C to +85°C.

The relative humidity must be non-condensable, with an annual average ≤80% and a maximum of 30 days a year ≤95%.

Electrical protection:

Security level is II.

All connectors have overvoltage class II and pollution class 2.

Other features: Comply with electromagnetic compatibility (EMC) directives and standards.

Noise resistance meets relevant standards.

Complies with industry standards such as NAMUR 21/8.98.
