SD802F 冗余电源模块

SD802F 是一款冗余电源模块，主要有以下参数和特点：

功能与应用：

SD802F 主要用于提供不间断的电源供应，保证设备或系统的稳定运行。

广泛应用于各种需要进行不间断电源供应的领域，如通信设备、服务器、工业自动化等。

电源特性：

双冗余24VDC+/—25%电源输入，带EMC滤波。

输出电压有3.3VDC+/—3%5A和5.0VDC+/—3%5A两种，总输出功率为26.5W。

输入及输出电压监控，提供电源故障信号。

过流检测及短路保护。

电源故障时输出保持20ms。

自动切换输入电源。

接口与通信：

诊测接口（带EMC滤波）用于诊测数据的EEPROM。

兼容性：

SD802F 电源模块可以插入到AC800F控制器的最左边的P槽。

该电源模块还设置了AC800F控制器的基本操作按钮及控制运运行状态指示灯显示。

The SD802F is a redundant power module that has the following parameters and features:

Functions and Applications:

The SD802F is mainly used to provide uninterrupted power supply to ensure the stable operation of the device or system.

It is widely used in various fields requiring uninterruptible power supply, such as communication equipment, servers, industrial automation, etc.

Power supply characteristics:

Dual redundant 24VDC+/ -25% power input with EMC filtering.

The output voltage is 3.3VDC+/ - 3%5A and 5.0VDC+/ - 3%5A, with a total output power of 26.5W.

Input and output voltage monitoring to provide power failure signals.

Overcurrent detection and short circuit protection.

Maintain the output at 20ms when the power supply fails.

Automatic switching of input power.

Interface and communication:

Diagnostic interface (with EMC filtering) EEPROM for diagnostic data.

Compatibility:

The SD802F power module can be inserted into slot P on the far left of the AC800F controller.

The power module is also equipped with the basic operation button of the AC800F controller and the indicator of the control operation status.
