X722F 模拟输入/输出模块

AX722F 3BDH000377R0001是一款功能丰富且性能出色的模拟输入/输出模块。

以下是关于这款模块的一些关键参数和特性：

通道配置：该模块提供了16个通道，其中八个通道可以单独配置为模拟输入，用于感测电压、电流或温度等参数。

AX722F 3BDH000377R0001 四个通道可以配置为模拟电压输出(-10 V至+10 V)或模拟电流输出(0…20 mA或4…20 mA)，其余四个通道可提供-10 V至+10 V范围内的电压信号。

电气性能：模块具有特定的电气特性，如没有dv/dt缓冲器但需要进行di/dt控制，以保持二极管的反向恢复在其安全操作区域内。

AX722F 3BDH000377R0001 还具有阻塞电压和高达6kA的截止电流，这些特性使得它在高功率应用中具有出色的表现。

尺寸与重量：模块的净深度/长度为30mm，净高为135mm，净宽度为68mm，净重为0.19kg。

应用领域：由于其卓越的性能和灵活的配置，AX722F 3BDH000377R0001模拟输入/输出模块在工业自动化、能源管理、环境监测等多个领域都有广泛的应用。

接口与兼容性：输入和输出与模块的其他电子电路电隔离。

AX722F 3BDH000377R0001 该模块可用于PROFIBUS远程I/O和AC 700F/AC 900F直接I/O，以及用于PROFIBUS从站和直接I/O。

The AX722F 3BDH000377R0001 is a feature-rich and high-performance analog input/output module.

Here are some of the key parameters and features of this module:

Channel configuration: The module provides 16 channels, eight of which can be configured individually as analog inputs to sense parameters such as voltage, current, or temperature.

AX722F 3BDH000377R0001 Four channels can be configured for analog voltage output (-10 V to +10 V) or analog current output (0... 20 mA or 4... 20 mA), the remaining four channels

can provide voltage signals in the range of -10 V to +10 V.

Electrical performance: The module has specific electrical characteristics, such as no dv/dt buffer but requiring di/dt control to keep the reverse recovery of the diode within its safe operating zone.

The AX722F 3BDH000377R0001 also has a blocking voltage and cutoff current of up to 6kA, which makes it excellent in high-power applications.

Size and weight: The net depth/length of the module is 30mm, the net height is 135mm, the net width is 68mm, and the net weight is 0.19kg.

Applications: Due to its excellent performance and flexible configuration, the AX722F 3BDH000377R0001 analog input/output module is widely used in many fields such as industrial automation,

energy management, and environmental monitoring.

Interface and compatibility: The input and output are electrically isolated from other electronic circuits of the module.

AX722F 3BDH000377R0001 This module can be used for PROFIBUS remote I/O and AC 700F/AC 900F direct I/O, as well as for PROFIBUS slave station and direct I/O.
