64711245C是 一款 可编程逻辑控制器（PLC）的模块。
接口与通信：64711245C该产品具有多个电接口，包括6个RJ45电接口，支持10Base-T/100Base-TX自适应，以及全双工/半双工自适应或强制工作模式。
光接口方面，它支持2个100Base-FX光接口，支持冗余环网，并可选SC/ST/FC接口，支持单模和多模光纤。
通信接口方面， 是CS513、MasterBus 300的替代品，具有自己的微处理器(CPU)以减少主CPU的负载。
网络与配置：64711245C使用光纤电缆在链路段中，两个站点之间的最大距离可以延伸至3500米（11480英尺）。光纤链路段最大可达1公里（3280英尺）。
通过使用有源星形耦合器，两个站点之间的最大距离可以进一步增加至4500米（14760英尺）。
它的最大RCOM/RCOM+传输速度为19200比特/秒。
电源与保护：电源设计为24VDC电源冗余输入（12VDC～36VDC），并内置过载保护、反接保护。
该产品提供1000V电磁隔离保护。
机械与工作环境：尺寸（高宽深）为136mm52mm105mm，采用IP30等级保护的波纹式高强度金属外壳。
工作环境方面，其工作温度范围为0℃～70℃，扩展工作温度范围为-40℃～85℃，存储温度范围为-45℃～85℃，湿度范围为5%～95%（无凝露）。
The 64711245C is a programmable logic controller (PLC) module.
Interface and communication: 64711245C The product has a number of electrical interfaces, including six RJ45 electrical interfaces, support 10Base-T/100Base-TX adaptive, and full
duplex/half duplex adaptive or forced mode of operation.
In terms of optical interface, it supports 2 100Base-FX optical interfaces, supports redundant ring network, and optional SC/ST/FC interface, supports single mode and multi-mode fiber.
In terms of communication interface, it is a substitute for CS513 and MasterBus 300, with its own microprocessor (CPU) to reduce the load of the main CPU.
Network and Configuration: 64711245C uses fiber optic cable in the link segment, the maximum distance between two stations can extend up to 3,500 meters (11,480 feet). Fiber optic
link segments up to 1 km (3,280 ft).
By using an active star coupler, the maximum distance between the two sites can be further increased to 4,500 meters (14,760 feet).
It has a maximum RCOM/RCOM+ transfer speed of 19,200 bits per second.
Power supply and protection: The power supply is designed for 24VDC power supply redundancy input (12VDC ~ 36VDC), and built-in overload protection and reverse protection.
The product provides 1000V electromagnetic isolation protection.
Mechanical and working environment: Size (H W D) is 136mm52mm105mm, using IP30 level protection corrugated high-strength metal housing.
In terms of working environment, the operating temperature range is 0 ° C to 70 ° C, the extended operating temperature range is -40 ° C to 85 ° C, the storage temperature range
is -45 ° C to 85 ° C, and the humidity range is 5% to 95% (no condensation).
